Specs:
Input : AC 100~240V 50/60Hz
Output: USB-C PD 3.0;5V/3A,9V/2A,12V/1.5A 18W max
USB-A QC3.0 3.6-6V /3A,6-9V/2A,9-12V/1.5A 18W max
Working Scenario :
*Only USB-C port working: Max 18W output, supporting PD or QC 3.0,PPS
*Only USB-A port working: Max 18W output, supporting QC 3.0
*Both ports working: No PD or QC output, together deliver max 5V 3.6A output
Dimension:(L)43.3*(W)41.3*(H)29.0mm
Ssfety standard:IEC/UL 62368
EMC standard:PART 15 Subpart B
Specs:
Input : AC 100~240V 50/60Hz
Output: USB-C PD 3.0;5V/3A,9V/2A,12V/1.5A 18W max
USB-A QC3.0 3.6-6V /3A,6-9V/2A,9-12V/1.5A 18W max
Working Scenario :
*Only USB-C port working: Max 18W output, supporting PD or QC 3.0,PPS
*Only USB-A port working: Max 18W output, supporting QC 3.0
*Both ports working: No PD or QC output, together deliver max 5V 3.6A output
Dimension:(L)43.3*(W)41.3*(H)29.0mm
Ssfety standard:IEC/UL 62368
EMC standard:PART 15 Subpart B
