WORKING ENVIRONMENT
Operation temperature:-10℃-45℃
Storage temperature:-20℃-70℃
Humidity:5%-95%RH
SPECIFICATIONS
Typical Output:5V2.5A/12V1.5A/24V0.65A
Output voltage:DC 5-24V
output current:1-1.5A
Rated input voltage:100-240Vac
Input Voltage Range:90-264Vac
Input frequency:50/60Hz
input current:400mA(rms)max@90Vac
Incrush current:30A max@240Vac
NO load power consumption:0.075W max
Energy class:
Safety standard:IEC/UL62368
EMC standard:Part 15 subpart B
WORKING ENVIRONMENT
Operation temperature:-10℃-45℃
Storage temperature:-20℃-70℃
Humidity:5%-95%RH
SPECIFICATIONS
Typical Output:5V2.5A/12V1.5A/24V0.65A
Output voltage:DC 5-24V
output current:1-1.5A
Rated input voltage:100-240Vac
Input Voltage Range:90-264Vac
Input frequency:50/60Hz
input current:400mA(rms)max@90Vac
Incrush current:30A max@240Vac
NO load power consumption:0.075W max
Energy class:
Safety standard:IEC/UL62368
EMC standard:Part 15 subpart B
